Deep Cycle 51.2V Golf Cart 48V Li Ion Battery LiFePO4 105Ah

  • 1
  • 2
  • 3

Brand Name : Elite Battery

Model Number : 51.2V 105Ah

Certification : CE, UL, MSDS, UN38.3,

Place of Origin : Guangdong, China

MOQ : 1 PCS

Price : $299.99-$2599.99/PCS

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal

Supply Ability : 10000 PCS/Month

Delivery Time : 30 Days

Packaging Details : Carton box with pallet

Capacity : 51.2V 105Ah

Nominal Voltage Voltage : 51.2V

Rated Capacity : 105Ah

Energy : 5376Wh

Application : ESS, Solar System

Cycle Span : 3000-5000 Cycles

Compact Desiged : With Built-in BMS

Self-diacharge Rate : <3%

Communication : CAN, RS232, RS485

OEM/ODM : Available

Contact Now

48V 51.2V 105Ah Golf Cart Li-ion Battery Deep Cycle LithiumLiFePO4 Battery

Battery Features

1. The battery pack consists of LFP cells, wire, BMS and metal case;

2. Long life, safety and wide temperature range;

3. High energy density, small size, light weight, no pollution;

4. Built-in BMS, with battery voltage, current, temperature and health management;

5. Integrated communication interface, CAN and RS485 communicate port are optional;

6. Easily for installation and operation

7. 10 years design life, stable performance, maintenance-free

Deep Cycle 51.2V Golf Cart 48V Li Ion Battery LiFePO4 105Ah

Battery Specification
Electrical Characteristics Nominal Voltage 51.2V
Nominal Capacity 105Ah
Energy 5376Wh
Internal Resistance ≤10mΩ
Cycle Life >6000 cycles@1C 100% DOD
Months Self Discharge <3%
Efficiency of Charge 100%@0.5C
Efficiency of Discharge 96-99% @1C
Standard Charge Charge Cut-off Voltage 58.4±0.2V
Charge Mode 0.2C to 58.4V, then 58.4V charge current to 0.02C(CC/CV)
Recommend Charge Current 55A
Max. Charge Current 100A
Standard Discharge Max. Continuous Discharge Current 200A
Max. Pulse Current 400A(35S)
Discharge Cut-off Voltage 40V
Environmental Charge Temperature 0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity
Discharge Temperature -20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity
Storage Temperature 0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity
Water Dust Resistance IP67
Mechanical Cell&Method 16S
Package Metal case
Dimensions(in./mm.) 509*334*230mm
Weight(lbs./kg.) 45kg
Terminal M8
Display screen Optional
Bluetooth Optional

Packaging & Shipping
With high quality pearl wool, UN cartons / Plywood, plastic pallet.
Standard batteries lead time: Samples: 15-20 days, Bulk order: 25-30 days.
Customized batteries lead time: Samples: 30-40 days, Bulk order: 30-40 days.
Shipment:By air, by sea, by express, by railway, etc.

Deep Cycle 51.2V Golf Cart 48V Li Ion Battery LiFePO4 105Ah

F&Q
1.Are your batteries safe?
A: Our batteries are safe. All Elite batteries use the safest and most stable components, including a LiFePO4 cathode and a built-in Battery Management System (BMS).The BMS protects the cells against excessively high or low voltages, high currents, short circuits, and excessive heat or cold. These are the most common causes of battery failures, and we have taken every precaution to mitigate these risks in all of our batteries.
2. What is your MOQ ?
Sample order for testing is available.

3. How can you guarantee your quality.
Elite implements strict quality control in every production process to ensure the stability and consistency of the products. We have a team of professional workers who are engaged in quality management during every process. Besides, all of our products have 3-5 years warranty.

4: Do you offer charger for battery?

A: Yes, we do. If you also need charger, please mention it when sending inquiry, kindly note that our charger cost is not included in the battery cost.

5. What shipping method can I choose? How about the shipping time?
By Express (3-15 days): suitable for urgent time or small quantity;
By Sea (25-45 days): suitable for bulk order;
By Railway (15-35 days): Suitable for bulk order.
Our sales person will recommend the most suitable solution for you according to your detailed order and situation.
